UGT-800
Feeler logo

Feeler UGT-800

SINUMERIK ONE NCU 1750 Controller 15” TFT Display Manual Guide i Spindle Big Plus CAT #40 [HSK A63] 15,000 rpm DDS w/ Oil Cooler Powerful 40 HP (30 kW) S6-40% Torque 140 lbf-ft (190 N.m) Oil Chiller DDM Table 31.5” (800mm) Diameter 2,640 lbs. (1,200kg) Load Capacity A-Axis Rotation Degree: ±120°, Max. Rotation Speed：50 rpm C-Axis Rotation Degree: 360°, Max. Rotation Speed：100 rpm ATC 32 Tools [48,64, 96,120] 30 bar CTS Unit and Filtering System Linear Scale on X/ Y/ Z/ A/ C Axis Fast 48 m/min (1,890 IPM) X, Y and Z Rapid Traverse X / Y / Z Roller Guide Ways Air Conditioner for Electric Cabinet Hydraulic Power Unit for A/C Axis Work Piece Air Blast Device by M-Code Spindle Coolant Nozzle and Ring Coolant Gun Auto Power Off Chip Conveyor Disc Type Oil Water Skimmer Transformer for 400V or 380V 3-Color Tower Signal Light CE Modification

The VORTEX UCT-600, UCH-660 and UGT-800 form a versatile family of advanced 5-axis machining centers engineered for high-precision, high-productivity manufacturing. The UCT-600 combines a rigid one-piece base-and-column structure with an A/C rotary table, separated machining and three-axis motion areas, and excellent operator access, making it a highly capable solution for precision parts across automotive, aerospace, medical and other demanding applications. The UCH-660 steps up to larger, heavier and more complex workpieces with its moving-column, swing-head design, 1,250 mm X-axis travel, high-rigidity construction and 12,000-rpm built-in spindle, providing exceptional flexibility for high-speed precision machining. At the top of the range, the UGT-800 delivers heavy-duty 5-axis performance with a highly rigid gantry and U-shaped structure, an 800 mm tilting rotary table supporting workpieces up to 1,200 kg, and a powerful 15,000-rpm direct-drive spindle, making it ideally suited for large, complex components requiring speed, accuracy and superior surface finish. Together, these three machines give manufacturers scalable 5-axis solutions for everything from precision production to demanding large-part machining.
Machine Type: Machining Center
Num. of Axes: 5
Operation Type: CNC
CNC Brand: Siemens
Table/Work Support
Table Size L x W (in.): 31.500(L) x 31.500(W)
Max Workpiece Weight (lbs): 2,646
Spindle(s)
Num. Main Spindles: 1
Direction: Vertical
Taper: #40
Top RPM: 15,000
HP (30 min rating): 39.00
HP Opt: 90.00
Tooling
Tool Carrier: ATC
Num. Tools: 32
Num. Tools Opt: 60
Axes And Travels
Num. Axes: 5
U Axis: None
Travel Max Feed Rate Rapid Traverse
X1 31.500" 1,890ipm
Y1 36.800" Opt: 49.200" 1,890ipm
Z1 25.200" 1,890ipm
B1 240.000°
